Pendant Project Part 3

Pendant Project Part 3

Part 3 of the V-Bezel pendant. Today we will finish soldering the pendant I started a couple of days ago, and I have a couple of clean-up tips for you before I get it ready to set the stone.

First I take the setting base and scribe a center line in the back of the half round bezel with Steel Dividers. This is just a location line so I know where to solder the bail. I picked a bail in the last post that had a diamond setting on it, but decided to cut it off because of strength and aesthetic issues. I used Handy Flux, Medium Solder, and my Mini Torch to solder the bail on. I hold the bail with Soldering Spring Tweezers and secure it with a Third Hand Tweezers.

Pendant 1 Pendant 2

After I solder the bail onto the setting, I clean the back with a Snap on Sanding Disc, make it flush, and add a Sterling Stamp.

Pendant 3 Pendant 4 Pendant 5

I next clean up the edges, making them sharp and crisp. I used a Barrette File, then I wrapped a piece of 600 grit sand paper around the same file and take out the file scratches. I also used a Knife Edge Silicone Wheel and  JoolTool 3M Bristle Brushes. These little babies work amazing for taking out scratches.

Pendant 9 Pendant 10 Pendant 8

Pendant 11 Pendant 12

Now if you have ever wondered how to polish inside places like the inside of a bail, here is a neat trick to get into those hard to get into spots. Get yourself some cotton string, (in different thicknesses) and rub polishing compound on it, now run the string through the bail and tie the other end to your bench. Rub back and forth and it will polish nicely. I use Graystar Compound first, then Red Rouge.

Pendant 6 Pendant 7

I also polish the tip of a burnishing tool on a piece of paper rubbed with Yellow Rouge and use it to polish the inside of the setting, if the setting base is polished, this will help the stone reflect more brilliantly.

Pendant 13 Pendant 14

Now the pendant is ready to set and polish. Stay Tuned.

By the way, make sure you subscribe if you haven’t, so you don’t miss ANY JewelryMonk Goodness.

Pendant 15

Now go make something Spectacular!

Doug

0

Pendant Project Part 2

Pendant Project Part 2


Ok, ok, After the V-Bezel illustration from a few days ago, I had quite a few comments about how I would use the bezels and a good application for V-Bezels. Well, you ask, you get.

Over the next few days I will make a pendant and set a stone using the now “semi-famous” V-Bezel. I found a stone that I have had in my drawer for a while looking for a use for it, well now I have found a purpose for it, so let’s get going.

First, I find a piece of flat silver for the pendant base. In this instance, I use a piece that is 1.25mm thick. I place the stone I am using top down on the silver, (I slightly dull the surface of the silver with a piece of used 1200 grit sandpaper so it will show the tracing better) and hold it in place with a small piece of sticky wax, something that will hold it firm. Once the stone is held down, I use a scribe to trace a light line around the stone. I pull the stone off of the silver and use my Saw Frame with a Saw Blade to cut along the outside of the line. I hold the silver with a pair of Smooth Jawed Parallel Pliers. I file the outside up to the scribed line.

Photo 1 Photo 2

Photo 3 Photo 4

Once I have the base cut out, I scribe an offset line inside, approx. 1.5 mm thick, then I drill a hole in the center of the base and load it on my Saw Frame. I cut along the inside up to the line, as close as possible. I use a Barrette Needle File and a Half-Round Escapement File to clean the inside and make it smooth and crisp.

Photo 5 Photo 6

Photo 7 Photo 8

Now I have the base cleaned up, I roll a piece of silver approx. 4mm wide and 0.8mm thick with my Rolling Mill to use as a bezel for the back of the stone. After I roll it to the desired thickness, I anneal it and form it to match the shape of the back of the setting. (If you are unfamiliar with the annealing process, see THIS BLOG ENTRY) I now solder the bezel to the back of the base that I made. You can see I place the solder in between the bezel and the frame on my Soldering Block. I solder using my Smith Mini Torch with a fairly small flame from the #5 torch tip. (I have drilled out my tip, so it is a little larger than a #5, but a #5 is a good tip) I am using Oxygen (approx. 30 psi) and Propane (approx. 10 psi) as gas for my torch. (to see how I set up my torch and to safely check for leaks, See THIS Blog Post)

Photo 10

Photo 11 Photo 12

Next, I take the V-Bezel that I made last time, and saw off about 4.5mm of it to use as a bezel setting for the point of the stone. I solder it to the point of the setting base while holding it with my Soldering Spring Tweezers with heat protective handles.

Photo 13 Photo 14

Can you see it starting to take shape yet? A little more massaging and it will come alive….. I found a bail that I have been itchin’ to use as well, seems like the perfect project for it.

Photo 15 Photo 16

Stay Tuned and I will finish cleaning it up and set the stone in the next days.

By the way, make sure you subscribe if you haven’t, so you don’t miss ANY JewelryMonk Goodness.

Now go make Something Surprising!

Doug

0

Pendant Project Part 1

Pendant Project

OK, if you have a little time, stick with me, over the next week or so I am going to take you on a journey, and at the end, we will end up in Cool-Pendant-Ville. But first, I am going to show you how to make just a small part of it, So pack your bags and let’s go!

If you are making jewelry long enough, eventually you are going to come across a project with a stone with a sharp corner, either a marquise, pear, or square shaped stone. Today I will demonstrate how I go about making a v-bezel for setting stones.
First, I find either a scrap piece of sheet silver or cut a piece off of some stock. I roll it down in my Rolling Mill to about 0.5mm and then anneal it. If you are unfamiliar with annealing, search “Anneal” on this blog, or CLICK HERE.

Bezel1 Bezel2

I then file a flat edge on one side of the silver and scribe a line approx 2.5mm away from the edge. (longer or shorter if you want longer or shorter bezels.) Once you have a line scribed, use a Square Graver or a Flat Graver at a 45 degree angle to cut a grove into the silver about 2/3 the way through the sheet. After the groove is cut, I run a Square Escapement File along the groove to make it uniform and straight.

Bezel3 Bezel4

Bezel5 Bezel6

Hold the silver sheet with a pair of Smooth Jaw Parallel Pliers with the grove even with the edge of the pliers and use a Square Prong Pusher to fold the sheet to a 45 degree (or square) angle. I also tap the silver with my Rawhide Mallet or a Plastic Head Jewelers Hammer to make sure it is seated against the other side.

Bezel7 Bezel8

Bezel9 Bezel10

Next I fluxed the solder joint with Handy Flux and add 3 pieces of small solder, spaced evenly, to the inside of the bezel. Do not use too much solder, you can always add more, but it is a pain if there is too much. I solder from the back side of the bezel with my Smith Mini Torch, to make sure the solder penetrates the solder joint.

Bezel11 Bezel12

Bezel13

Now measure the finished side and scribe a line along the other side the same width, and cut with your Jeweler Saw Frame. (I use a 3/0 Saw Blade) Again, you can trim the sides either longer or shorter, and use thicker or thinner silver, depending on the application you are using.

Bezel14 Bezel15

Bezel16

Now trim off the amount you want and solder to your stone seat or pad.

OR…. Stay tuned and see what I will do with this……
Now, go make something AMAZING!
Doug

2

020 Podcast Cleaning your Files, Pin Vises, Jewelers For Children

JewelryMonk Podcast Episode 21

In this Episode I talk about Educating, Equipping, and Encouraging, The 3 E’s that keep me going

Our Featured Artist of the Week is Jewelers For Children. Here is a quick video highlighting some of their work. You can also check them out at www.jewelersforchildren.org

The Jewelry Tip of the Week is all about Cleaning Files. I described 2 ways I do this, and I made a quick video how I clean my needle files with a Crimped Wire Steel Cup Brush. Here is a link to the brushes, and a short video:

ALSO a FREE Downloadable CAD Volume to Metal Conversion Worksheet!

CLICK HERE

I also talked about my Cool Tool Pick of the Week, Pin Vises. Here are a couple of the ones I use, as well as a link to the same ones I use. They are pretty inexpensive, and well worth the price.

Single Ended Pin Vise

Double Ended Pin Vise

ALSO, I Talked About the A to Z Design to Finished Jewelry Video Course

http://jewelrymonk-llc.thinkific.com/courses/AtoZ

The A to Z Design to Finished Jewelry Course is a 10 lesson, 22 video series that takes you through creation a piece of jewelry, from concept and drawing, all the way to the completed piece of reproducible jewelry. The videos cover, in real time, all the processes from transferring your design onto a wax blank, preparing and carving the wax. Casting that wax into silver, and cleaning up the silver into a model that will be molded. Injecting wax into the mold and casting those waxes into silver. Preparing those castings with tumbling media and polishing the castings. Finally, the piece will be set with a pear shaped stone in a prong/bezel setting, and the piece of jewelry will be final polished and cleaned, ready to ship. Link on the right side of this page, or above.

Plus lots more in the podcast……

Now, Let’s Make something Shiny, Together.

Doug

FREE 3D Volume to Metal Conversion Worksheet

Little different content today, but I created this FREE WORKSHEET and wanted to share.

Have you ever created a 3D CAD file and wondered how much it would weigh in different metals?

For those of you who create or dabble in the digital world, I created a worksheet that converts 3D models (volume) into weights of different types of metal based on the metals specific gravity. Just enter the volume number from your 3D Program into the space associated with the metal you want, and it will magically give you your metal weight……. ok, more math than magic, but it is quick and easy.

CLICK HERE

For those of you who don’t know, I also have a website www.DougNapier.com, which is an extension of JewelryMonk.com that focuses on Providing CAD, Model Making, and Product Development to the Jewelry Manufacturing Community, as well as Consulting and Training Jewelers in a Manufacturing setting.

Between traveling a bit and focusing on building this site, that is where I have been for the past couple of months. I am not going anywhere, and will be back to creating more free content very soon…… oh, and will get back to more podcasts as well.

Thanks for stopping by, now go make something…….digital?

Doug
